407A MODEL

Duo check, cast iron

Flange connection PN 10/16

Application: liquids and gases
» Compact
» Easy installation
» Horizontal – or vertical mounting

GENERAL DATA
  • Type: 407A
  • Material: Cast iron GG25
  • Pressure class: PN 16
  • Disc: Stainless steel AISI 304
  • Spring: Stainless steel
  • O-rings: EPDM
  • Temperature: -10ºC to 100ºC
  • Options: House and disc in other materials; Dimensions up to DN600; Other connections and pressure stages
