541 MODEL

Check valve in stainless steel 316

RG – female threaded, Spring-loaded

Application: Water, non-aggressive liquids and gases
» Universal mounting

GENERAL DATA
  • Type: 541
  • Material: AISI 316
  • Pressure class: PN 16
  • Disc: 316
  • Sealing: FKM(viton). Option EPDM, PTFE or NBR
  • Spring: AISI302
  • Connection: Female threaded acc. to ISO 7/1
  • Temperature: NBR -25ºC to 90ºC; EPDM -20ºC to 110ºC; FKM -20ºC to 150ºC; PTFE -20ºC to 200ºC
